Expandable Container Camp with Double Wing
Feature of the expandable container house:
Spacious Design: The double wing folding house design offers ample living space, enhancing comfort and usability.
Portability: As a 20ft expandable portable home, it can be easily transported to various locations, providing flexibility for different accommodation needs.
Versatility: Suitable for a range of applications, including as an expandable living house or an expandable container camp.
Quick Assembly and Disassembly: This expandable prefab container house can be set up or taken down swiftly, making it suitable for rapidly changing circumstances or emergency situations.
Cost-Effective: Utilizing an expandable container camp structure provides an affordable solution compared to traditional housing options.
☞☞☞Click this link to view more videos from JM’s YouTube!
Material List
| Steel Structure | List | Part Name | Specification |
| 1 | Steel column | Steel panel 3mm thickness bend part | |
| 2 | Main bottom beam | 150*75*3.0mm | |
| 3 | Main top beam | 12#*6mm | |
| 4 | Secondary beam | 80*80*2.0mm | |
| 5 | Panel | Galvanized steel corrugated sheet 1.0mm | |
| 6 | Bottom frame purlin | 80*40*2.0mm | |
| Panel, Door, and Window | 7 | Ceiling | 1150*50*0.326mm double-side Choi foam sandwich panel |
| (White and grey) | |||
| 8 | External wall panel | Bending piping 2.5mm+1150*50*0.326mm 0.326mm double side Choi foam sandwich panel | |
| (White and grey) | |||
| 9 | Floor | Fireproof panel 15mm (yellow) +PVC grain board | |
| 10 | Door panel | 304 SS door (primary colors)
W*H: 1520mm*2200mm, 1 set |
|
| 11 | Sliding window | Aluminum alloy sliding window (white)
W*H: 930mm*1200mm, 8 sets |
